Introduction to the Haydon HAY-PSUMULTI10A and its key features
The Haydon HAY-PSUMULTI10A is a purpose-built 16-way 12 V DC CCTV power supply designed for professional installers and systems integrators who need a compact, secure and reliable way to power multiple cameras and accessories from a single enclosure. Marketed as the Haydon Multi-Output 12V DC Power Supply (16-Way 10A), this boxed unit offers regulated and filtered outputs, per-channel protection and visible LED status indicators — all inside a lockable metal housing. With a total unit output limited to 10 A (approximately 120 W), it is targeted at small to medium multi-camera installations where centralised power management, fault isolation and tidy cabling matter.
Key features at a glance
- 16 individual regulated 12 V DC outputssuitable for cameras and low-voltage accessories.
- Per-output protectionusing PTC/fused outputs plus surge protection to prevent single faults from taking the whole system offline.
- LED status indicatorsfor every output visible through a clear front window for quick on-site diagnostics.
- Secure metal enclosurewith internal mains on/off switch and a mains fuse (3 A fitted) for safety and theft protection.
- Wide mains inputcompatibility: 110–240 VAC, making it suitable for many regions.
Detailed specifications and benefits
Understanding the HAY-PSUMULTI10A’s specifications helps clarify where it fits in a CCTV installation. The key electrical specs are straightforward: a regulated and filtered 12 V DC output, a maximum total output current of 10 A, and an approximate maximum output power of 120 W. The mains input range of 110–240 VAC means installers can deploy the unit in different countries with minimal concern for local supply voltage.
- 16 individual outputs:This allows you to power up to 16 cameras or accessory devices centrally. Outputs 1–4 are higher-rated than outputs 5–16 — many listings show outputs 1–4 with per-output ratings between ~1.6 A and 2.5 A, while outputs 5–16 are commonly listed around 1.1 A each. Because published per-channel values vary between resellers, always consult the manufacturer datasheet or vendor confirmation for the authoritative values.
- Per-output protection:Each channel is protected by PTC devices / fuses so that a short or overload on one camera won’t disable all other outputs. This isolation saves troubleshooting time and avoids full-system downtime.
- Surge protection:Built-in surge mitigation helps protect sensitive camera electronics from transient mains events.
- LED indicators:A visible LED per output (through a front window) lets installers and maintenance staff perform rapid visual checks without opening the enclosure.
- Enclosure:Boxed metal body with clear front window; lockable to deter tampering and unauthorised access.
- Dimensions and weight:Approximately 240 × 205 × 65 mm and about 1.8 kg, making the unit compact enough for wall-mounting in plant rooms or equipment cabinets.
- Operating environment:Typical listings indicate an operating temperature range of approximately −10°C to +50°C and storage down to −20°C. Humidity tolerance is generally 0–90% RH non-condensing.
- Safety features:Internal mains on/off switch and mains fuse (3 A) are fitted for practical protection and maintenance safety.
- Compliance:Reseller and manufacturer pages typically list CE and RoHS compliance; confirm specific certifications and UKCA marking from the datasheet when required for a project.
- Installation:Must be installed by a competent or electrically qualified person following local electrical regulations. It is not intended for direct outdoor exposure and should be mounted in a secure, suitable location.
Benefits: why these specifications matter on-site
Centralising power for multiple cameras simplifies cabling and inventory management. Instead of deploying many individual power adapters (which can clutter racks and introduce numerous single points of failure), the HAY-PSUMULTI10A consolidates supplies into one neat, serviceable unit. Per-output protection reduces the time spent troubleshooting: a blown fuse or tripped PTC is isolated to the affected camera and can be quickly identified by the LED indicators. The regulated and filtered outputs help maintain consistent camera performance, reducing flicker or image degradation caused by unstable power.
Use cases and scenarios where the HAY-PSUMULTI10A excels
This power supply is especially appropriate for the following common applications:
- Small to medium business CCTV systems:Retail stores, small offices and restaurants that need to power multiple fixed or bullet cameras without large-scale power infrastructure.
- Multi-camera residential / apartment blocks:Communal CCTV systems in apartment buildings where a single, secure, lockable power unit simplifies maintenance and reduces tamper risk.
- Educational or municipal sites:Schools and council buildings where a centralised power provision with per-output protection eases management across multiple camera locations.
- Temporary or semi-permanent installations:Sites where installers need a quick, neat solution for powering a cluster of cameras during events or short-term deployments (provided the environment is suitable and the unit is mounted securely indoors).
- Systems requiring quick diagnostics:Installations where rapid visual status checks are important — the front-window LED indicators speed up routine checks without opening the box.
Comparisons with similar products on the market
When choosing a multi-output CCTV power supply you typically weigh centralised units like the HAY-PSUMULTI10A against several alternatives: individual power bricks, basic multi-output supplies without per-output protection, and high-end power systems with battery backup and networked monitoring.
Individual plug-in adapters can be cheap and flexible, but they create cable clutter, multiple failure points and a less secure installation. The Haydon unit costs more up front than a single adapter but reduces long-term labour, organisation and the risk of accidental disconnection.
Lower-cost multi-output boxes that lack per-output fusing or LED indicators may appear cheaper but can leave a whole system vulnerable to a single short. The HAY-PSUMULTI10A’s per-output protection and LEDs are practical advantages for installers who need robustness and maintainability.
Enterprise power units with remote monitoring, higher total current, or integrated UPS/battery backup provide features the Haydon lacks. If you need remote alerting, SNMP, or uninterrupted power during mains failures, a managed or UPS-backed system is a better fit. The HAY-PSUMULTI10A, however, offers an attractive price-to-feature balance for many small and medium deployments where those advanced features aren’t required.
Customer feedback and representative installer comments
While individual reviews will vary, installers and small systems integrators typically praise the following aspects of the HAY-PSUMULTI10A:
- "Practical per-output protection — a single camera fault doesn’t bring down the system."
- "LED indicators through the front window save time during routine checks and cuts down service visits."
- "Good value for a 16-way boxed solution — compact enough to fit in plant rooms and cabinets."
Some common caveats mentioned by users include verifying the exact per-output ratings for outputs 1–4 (as listings sometimes differ) and noting that the unit is not a substitute for a UPS if continuous operation during mains loss is required. As always, check the manufacturer datasheet and confirm per-output amperage if the cameras you plan to use draw near the per-channel limits.
Conclusion: why the Haydon HAY-PSUMULTI10A is a strong choice
The Haydon HAY-PSUMULTI10A is a pragmatic multi-output 12 V DC power supply that balances cost, safety and practicality for many small-to-medium CCTV installations. Its regulated outputs, individual PTC/fuse protection, front-panel LED indicators and secure metal enclosure make it a reliable central power option that simplifies wiring and ongoing maintenance. While it doesn’t replace higher-end monitored or UPS-backed solutions where continuous uptime and remote management are essential, its compact form factor and per-output protection make it an excellent choice for installers seeking a tidy, serviceable and cost-effective power solution.
Suggested retail pricing for this product often sits in the mid-range for 16-way boxed units (a typical suggested price is around 64.99). As always, verify current pricing, warranty terms and per-output ratings with your supplier or the manufacturer datasheet before purchasing and installation.
