Introduction: ACC2PMLA 6m Tilt‑Down Post‑Mount CCTV Column — what it is and why it matters
Altron ACC2PMLA — 6.0 m tilt‑down post‑mount CCTV columnis a purpose‑built, modular column engineered to provide a secure, durable mounting solution for CCTV cameras across car parks, transport hubs, industrial estates and commercial sites. The ACC2PMLA combines a tall 6.0 m profile with a tilt‑down capability that enables safe ground‑level maintenance and servicing. Constructed from high‑tensile steel and finished by hot‑dip galvanising after fabrication, this column is intended for long service life with low ongoing maintenance.
Key features at a glance
- Height:6.0 m — elevated camera position for wide coverage.
- Tilt‑down design:Allows lowering the column to ground level for maintenance, reducing the need for cherry pickers or scaffolding.
- Construction & finish:High‑tensile steel, hot‑dip galvanised after fabrication (optional paint to BS/RAL).
- Security & cabling:Internal cable routing, flush access doors and an internal padlock facility to prevent unauthorised lowering.
- Modular, demountable:Supplied in sections for easier transport and on‑site assembly.
- Typical accessories:Recommended winch (DW1000/AC), foundation template/bolts (usually sold separately).
Detailed specifications and benefits
- Model / Part: ACC2 PMLA (ACC2PMLA)
- Height: 6.0 m
- Style: Square section — Tilt‑down
- Root fixing / Base: Post‑mount / set in concrete (direct burial)
- Construction material: High‑tensile steel
- Finish: Hot‑dip galvanised after fabrication (option to paint to BS/RAL)
- Internal features: Internal cabling space; flush access doors; internal padlock facility
- Door aperture: 270 x 80 mm (typical)
- Max equipment weight: Approx. 25 kg (typical ACC2 rating)
- Mass (column only): Approx. 115 kg
- Recommended winch: DW1000/AC (catalogue recommendation)
- Foundation / template: Foundation template / bolts usually sold separately
- Supplier code: ITM002714
The ACC2PMLA is manufactured from high‑tensile steel and hot‑dip galvanised after fabrication. Hot‑dip galvanising provides robust protection against corrosion, particularly important for external installations exposed to rain, salt and pollution. The galvanised finish reduces the need for frequent repainting and supports long‑term structural integrity—an important consideration for infrastructure that must remain dependable with minimal downtime.
One of the defining advantages of the ACC2PMLA is its tilt‑down mechanism. Routine servicing—such as camera adjustments, lens cleaning, cable work or component replacement—can often be carried out safely from ground level once the column is lowered, avoiding the logistical costs and safety risks associated with elevated working platforms. The flush internal access doors and integrated padlock facility add an extra layer of security, preventing unauthorised lowering of the column and protecting installed equipment and cabling.
Supplied as modular, demountable sections, the column is straightforward to transport and assemble on site. This reduces freight complexity and allows for flexible installation planning, especially in locations with restricted access or challenging delivery conditions. Note that a suitably engineered concrete foundation and correct fastenings are required—the foundation template and bolts are commonly ordered separately and the recommended winch (DW1000/AC) is typically specified to operate the tilt‑down action.
Use cases and scenarios where the ACC2PMLA excels
- Car parks:Wide overhead coverage with elevated camera positions gives better overview of vehicle movements and parking bays. Tilt‑down access streamlines maintenance without disrupting parking operations.
- Rail and transit platforms:Provides durable mounting where frequent inspections are needed and quick maintenance access is a priority for safety and uptime.
- Industrial sites and logistics yards:Robust construction suits harsher industrial environments; internal cabling keeps wiring protected from damage and tampering.
- Commercial premises and retail parks:Neat, galvanised finish and optional paint to match branding or site aesthetics.
- Temporary or phased installations:Demountable sections make it simple to dismantle and re‑use the column when site requirements change.
Comparisons with similar products on the market
When evaluating mounting columns for CCTV, buyers commonly consider fixed columns, tilting single‑mast solutions, telescopic poles and gantries. The ACC2PMLA should be compared on several dimensions: maintenance access, durability, ease of installation, capacity and security.
Fixed columns are usually simpler and may cost less up front, but they require elevated access solutions (lifts, scaffolding) for servicing. The ACC2PMLA’s tilt‑down functionality reduces recurring maintenance costs and safer servicing operations, which frequently offsets any initial price difference over the column’s lifetime.
Telescopic columns provide adjustable height but can be mechanically complex and often require specific hydraulic or electric systems. The tilt‑down post‑mount design offers a simpler mechanical approach to maintenance while delivering a fixed, stable 6.0 m working height—ideal when a constant elevated position is preferred.
Round or decorative columns may be chosen for aesthetic reasons but can lack the internal space and access features of the ACC2PMLA. The square, modular design of the ACC2PMLA provides practical internal routing for cables, larger internal clearances and secure access doors, making it more suitable for functional surveillance installations where equipment protection and serviceability are priorities.
Price and value proposition
The ACC2PMLA is positioned as a robust, serviceable solution for professional CCTV installations. The suggested retail price is 925.00 (confirm current pricing and options with your supplier). Accessories such as the winch (DW1000/AC), foundation template/bolts and delivery are typically additional. Buyers should factor the total installed cost—column, foundation, winch, installation labour and any surface treatment—when assessing value. The tilt‑down capability and galvanised construction mean lower lifetime maintenance costs and longer service life compared with many basic alternatives.
Customer feedback and representative testimonials
Below are representative examples of the types of feedback installers and site managers commonly provide for tilt‑down modular columns like the ACC2PMLA. These are anonymised, illustrative comments reflecting recurring themes from site experience.
- "Great serviceability — much easier to service cameras and replace equipment without traffic management or hire of a cherry picker."
- "Robust build and the galvanised finish meant no signs of corrosion after several seasons in an exposed car park."
- "Modular sections made it simple to transport and lift into position on a site with narrow access."
When considering feedback, ask suppliers for case studies or references specific to your industry sector—these can provide real‑world performance and installation insights for the ACC2PMLA variant you intend to buy.
Installation & compliance notes
Installation requires a suitably engineered concrete foundation and correct fastenings. The foundation template and bolts and the winch kit are commonly supplied as additional items—confirm items and compatibility with your supplier. Always confirm UKCA/CE marking and the exact variant details before purchase. Installation should be performed by qualified personnel in accordance with local regulations and the Altron installation guide to ensure safety and long‑term reliability.
Conclusion: why choose the ACC2PMLA
The Altron ACC2PMLA 6m tilt‑down post‑mount column blends practical design, durable construction and service‑focused features to meet the needs of commercial, industrial and transport surveillance installations. Its tilt‑down maintenance capability reduces operating costs and safety risks associated with elevated working, while hot‑dip galvanising ensures long term corrosion protection. Modular logistics and secure internal cable routing make it a pragmatic choice where uptime, security and ease of service are priorities. For sites requiring a reliable, maintainable mounting solution at a 6.0 m elevation, the ACC2PMLA offers a balanced mix of functionality and value.
