Introduction: Meet the AC1300 Ceiling/Wall Access Point (RG‑RAP2200(E))
Ruijie Reyee RG‑RAP2200(E)is an AC1300 cloud‑managed indoor wireless access point designed for neat ceiling or wall installations. Combining dual‑band Wi‑Fi 5 performance with 2×2 MU‑MIMO, two Gigabit Ethernet ports (one with PoE), and integrated omnidirectional antennas, the RG‑RAP2200(E) targets small‑to‑medium enterprises, hospitality, education and retail environments that need reliable Wi‑Fi, simple centralised management and clean aesthetics.
With combined theoretical throughput of up to 1.267 Gbps (400 Mbps on 2.4 GHz + 867 Mbps on 5 GHz), support for up to eight SSIDs with per‑SSID VLAN and security policies, and cloud management via Ruijie/Reyee Cloud, this AP is positioned as a practical, cost‑effective choice where performance and manageability matter.
Key features at a glance
- AC1300 dual‑band Wi‑Fi 5:2.4 GHz up to 400 Mbps and 5 GHz up to 867 Mbps with 2×2 MU‑MIMO.
- Dual Gigabit ports:2 × 10/100/1000Base‑T ports with LAN1 supporting 802.3af/at PoE for flexible power and uplink options.
- Ceiling/wall form factor:Integrated 2 dBi omnidirectional antennas for discreet indoor deployments.
- Cloud management:Centralised provisioning, monitoring, self‑organising mesh and one‑click RF optimisation via Ruijie/Reyee Cloud.
- Multi‑tenant and policy control:Up to 8 SSIDs, per‑SSID VLAN and security settings, layer 2/3 roaming for seamless mobility.
Detailed specifications and the benefits they deliver
The RG‑RAP2200(E) implements IEEE 802.11ac Wave 2 (Wi‑Fi 5) with 2×2 spatial streams and MU‑MIMO, delivering a combined theoretical throughput of 1.267 Gbps. That performance profile is well‑suited to mixed client populations typical in hospitality and office settings: legacy devices on 2.4 GHz, and modern phones, tablets and laptops on 5 GHz.
Benefits:
- MU‑MIMO improves simultaneous experience for multiple users, reducing airtime contention in busy public areas.
- Dual‑band operation allows client steering and more efficient use of the 5 GHz spectrum when available.
The AP includes two Gigabit Ethernet ports (LAN1 with PoE), supports 802.3af/at, and can alternatively be powered with an optional DC 12V/1.5A adapter. Power consumption is modest (≤ 12.95 W), and the compact 194 × 194 × 35 mm design with integrated antennas keeps site cabling tidy.
Benefits:
- PoE support simplifies deployments in ceilings where AC outlets are unavailable or undesirable.
- Dual ports allow uplink plus passthrough or local LAN connectivity for devices such as IP phones or small switches.
- Low power draw reduces operating costs and heat in dense AP environments.
On the software side, the RG‑RAP2200(E) supports up to eight SSIDs with per‑SSID VLAN tagging and security policies, layer 2/3 roaming for seamless client handoffs, and recommended client handling of around 40 active users per AP (maximum supported clients 110). Cloud management provides centralised visibility, one‑click RF optimisation and simple onboarding for scaled deployments.
Benefits:
- Multiple SSIDs and VLANs let administrators segment guest, staff and IoT traffic without extra hardware.
- Cloud management reduces on‑site maintenance and accelerates rollouts across multiple locations.
- Self‑organising mesh can lower cabling needs where wiring every AP is impractical.
Use cases and scenarios where the RG‑RAP2200(E) excels
This AP is designed for environments that combine requirements for unobtrusive installation, central management, and predictable Wi‑Fi behaviour. Typical deployments include:
- Hotels and hospitality:Ceiling mounting keeps units discreet in guest rooms, lobbies and meeting spaces. Multiple SSIDs and VLANs separate guest access, back‑office Wi‑Fi and IPTV or POS services.
- Small‑to‑medium enterprises and branch offices:PoE simplifies installation in leased office spaces while cloud management allows IT to oversee multiple sites from a single console.
- Education and classrooms:The AP supports dense user populations in lecture halls and classrooms with MU‑MIMO and roaming features to maintain session continuity as students move between rooms.
- Retail stores and cafes:Integrated antennas and a low profile preserve shop aesthetics while separate SSIDs support guest Wi‑Fi and staff back‑end systems.
- Temporary or retrofit installations:Self‑organising mesh and dual Ethernet ports let installers choose between wired uplink or wireless backhaul without redesigning floor cabling.
How it compares to similar products on the market
The RG‑RAP2200(E) sits in the value to midrange segment of indoor APs. Here are practical comparisons to consider when selecting hardware:
Compared with older AC1200 or AC750 models, the RG‑RAP2200(E) offers meaningful throughput gains on the 5 GHz band and MU‑MIMO support, making it a better fit for modern client mixes. It also benefits from Ruijie cloud management — an advantage over entry‑level APs that require on‑prem controllers or manual configuration.
Higher‑end AC1750 or Wi‑Fi 6 (AX) APs will deliver greater throughput, more spatial streams and often superior capacity in very dense environments. However, those devices come at higher cost and power demands. The RG‑RAP2200(E) strikes a balance: it provides modern features such as MU‑MIMO and cloud management at a price point that makes widespread deployment affordable for many organisations.
Compared to other cloud‑managed options, Ruijie/Reyee Cloud offers the expected advantages of centralized provisioning, monitoring and optimisation. When evaluating vendors, consider the ecosystem: integration with existing switches, warranty and support, cloud feature set (e.g., analytics, guest portals) and licensing model. The RG‑RAP2200(E) is competitive where teams want a straightforward cloud experience without the licensing premiums some competitors impose.
Customer feedback and real‑world observations
Direct customer testimonials for this specific model may vary by region and deployment, but installers and network administrators typically highlight a few consistent positives for APs with this feature set:
- Ease of installation: PoE support and a compact mounting kit make ceiling/wall installs straightforward for qualified technicians.
- Centralised management: Cloud onboarding and monitoring reduce time spent on routine maintenance and troubleshooting across multiple sites.
- Good value: For organisations that need reliable Wi‑Fi without investing in the highest‑end hardware, an AC1300 device like the RG‑RAP2200(E) balances performance and cost.
Administrators also often note practical considerations: keep expected concurrent client counts in mind (recommended ≈ 40 active users for optimal performance), and use the 5 GHz band where possible to maximise throughput for modern devices. For high‑density venues or areas with heavy 4K streaming, consider mixing in higher‑capacity APs or additional units to maintain experience.
Conclusion: Why choose the RG‑RAP2200(E)?
TheRuijie Reyee RG‑RAP2200(E)is a balanced, cloud‑ready indoor access point that answers a common set of needs for hotels, SMBs, education and retail: reliable dual‑band Wi‑Fi with MU‑MIMO, PoE flexibility, unobtrusive ceiling/wall mounting and centralised cloud management. It provides a pragmatic mix of performance (AC1300), manageability and price that makes it well suited to organisations looking to deploy multiple APs without excessive complexity or cost.
When planning a wireless deployment, consider client density, the role of each AP (coverage vs. capacity), and whether cloud management and mesh features align with your operational model. For many sites, the RG‑RAP2200(E) offers an attractive balance of features, making it a compelling choice for clean, manageable and modern indoor Wi‑Fi infrastructure.
